Below is steel and aluminium that SINO deal with,Any further special,let SINO Know by email or by Call.
Grade Standard CHEMICAL COMPOSITION(% MAX)
GB JIS UNS KS BS EN C Si Mn P S Cr Ni Cu N Mo Ti
201 12Cr17Mn6Ni5N SUS201 S20100 STS201 1.4372 0.15 1 8-10.5 0.06 0.03 13.16 1.0-3.0 2 0.2
202 12Cr18Mn8Ni5N SUS202 S20200 STS202 1.4373
304 06Cr19Ni10 SUS304 S30400 STS304 1.4301 0.07 1 2 0.05 0.02 17.5-19.5 8-10.5
304L 022Cr19Ni10 SUS304L S30403 STS304L 1.4306 0.03 1 2 0.05 0.02 17.5-19.5 8-10.5 0.1
316L 022Cr17Ni12Mo2 SUS316L S31603 STS316L 1.4404 0.03 0.75 2 0.045 0.03 16-18 10-14.0 0.1
309S 06Cr23Ni13 SUS309S S30908 STS309S 1.4833 0.03 0.75 2 0.045 0.03 16-18 10-14.0 0.1
321 06Cr18Ni11Ti SUS321 S32100 STS321 1.4541 0.02 0.73 0.97 0.03 0.001 17.21 9.16 0.15 0.0126 0.13 0.26
310S 06Cr25Ni20 SUS310S S31008 STS310S 1.4845 0.035 0.61 1.08 0.028 0.001 24.6 19.2 0.23 0.0518 0.1
430 10Cr17 SUS430 1.4016 0.04 0.32 0.4 0.024 0.002 16.06 0.1
904L 1.4539 1 2 0.045 0.035 23 28 2 5

Service makes value.

Quality defines our profession.

Customer service is our key priority.

Division Description Temper Thickness (mm) Application Feature
1000 SERIES 1050 1060 1070 1100 1235 representative series aluminum sheet/coil is also known as pure aluminum, in the series in 1xxx series belongs to all the alumina quantity of a maximum number of series. Purity can achieve 99.00% above. All tempers 0.2-8.0 Utensil, decoration, Reflecting plate, printing plate, heatproof plate,cookware Easy to process and weld,resistant to rust,high,conductibility of electricity and heat,low strength
2000 SERIES 2011. 2A12,2A16,2A06,2014. 2017. 2018. 2024. 2025. 2117. 2218. 2618 representative series aluminum foil and sheet . All tempers 0.2-600 Aerospace structural storage,liquid transportation,tanker,curtain wall,mechanical parts high strength and hardness,better heat resistance
3000 SERIES 3xxx series aluminum represents 3003 3004,3005, 3 A21 primarily. And can be called in the 3xxx series aluminum antirust aluminum production process more outstanding. The 3xxx series aluminum plate is by manganese as the main component. Content at 1.0-1.5 between. Is a rust-proof function better series. Conventional application in the air conditioning, the refrigerator, such as car in damp environment. All tempers 0.2-8.0 Utensil(F/P, inside of rice cooker), aluminum can,material for interior and exterior of building,chemical equipment,Cellular Phone 20% higher strength than the 1100 series, easily welded and brazed, good antirust,ability Non-heat treatable
5000 SERIES 5xxx series representatives 5052 5005 5083,5754. The 5000 series aluminum alloy aluminum belong to the more commonly used series, the main elements for magnesium, with magnesium in the amount between 3-5%. And can be called aluminum magnesium alloy. Key features for low density, high tensile strength, elongation rate is high. In the same area under the weight of the magnesium alloy aluminum less than other series. All tempers 0.15-600 Ship board heatproof apparatus, material for interior and exterior of building, Parts of Electronic tools.Automobile Components Excellent corrosion resistance andweld ability together with Easy to process and weld and superior hardness &heat proof .Can be anodized for increased corrosion resistance
6000 SERIES 6xxx series represents 6061 mainly contain magnesium and silicon of two elements, so focused on the 4000 series and the advantages of the 5000 series 6061 is a cold treatment aluminum forging products, apply to fight against corrosion, oxidizing demanding applications. O,T4,T6,T651 0.2-600 IT equipment & facility,Mould material, motor material, automatic line, machine & plant etc Easy to process , good corrosion resistance, high toughness and processed without distortion after heat-treatable, superior surface treatment
7000 SERIES 7xxx series aluminum alloy is another common alloy, wide variety. It contains zinc and magnesium. The best strength in the common aluminum alloy is 7075 alloy, but it can't be welded, and its corrosion resistance is rather poor, many manufacturing parts with CNC cutting is 7075 alloy. O,T6,T651,T7451 0.2-600 The aerospace industry & High strength accessories 7000 series is high tensile to process with special alloy
8000 SERIES 8xxx series aluminum alloy with excellent sealing, plastic, anti-corrosion and other features, representative series 8011,8021,8079
All tempers 0.01-0.3 Beer label, cable, pharmaceutical packaging, household foil food packaging, bottle cap material, heat sealing foil, etc. Beautiful appearance, high gloss, clean and sanitary
